2G 3G 4G Tri Band Repeater

Name: 2G 3G 4G Tri Band Repeater
Brand: ATNJ
Price: 240 USD

Quality 2G 3G 4G Tri Band Repeater for sale

Brand Name : ATNJ

Model Number : JS-DB900/1800/2100

Certification : CE,ROHS，CCC，TUV,BV， ISO

Place of Origin : China

MOQ : 5Pcs

Price : USD+240---260+kit

Supply Ability : 1000+unit+per day.

Delivery Time : 3-5 work days

Packaging Details : Standard neutral packing,52x21x16cm(1 kit), 4kits as 1 carton(53x49x42cm)

Payment Terms : T/T,Western Union,Paypal,Bank transfering

Frequency Range : According to customer's need,(Band1) 2100MHz -- Uplink frequency: 1920-1980MHz/Downlink frequency : 2110-2170MHz (Band 3) 1800MHz -- Uplink frequency: 1710-1785MHz/Downlink frequency : 1805-1880MHz (Band 8) 900MHz -- Uplink frequency: 890-915MHz/Down

Gain : 70dB

Output power : 20dBm

Color : Black ,Cuztomized

AGC Intelligent function : Done,31dB @ 1dB/ Step

ALC Intelligent function : Done

MGC : Done

In-band Ripple : ≤ 3dB

VSWR : <=2

Noise Figure : ≤ 5dB

System Delay : ≤ 5μs

RF Connect Type : N/Female

Power Supply : AC 110~220V±20%, 50/60Hz(AC 220V/ DC5V/2A power adapter)

Inter-Modulation Attenuation ACPR : ≤ -40dBc / 30kHz (measured under rated output power)

Weight : 3.5kg

Packing size : 52x21x16cm

Contact Now

2G 3G 4G Tri Band Repeater

Full intelligent 2G 3G 4G Mobile Signal Booster 900/1800/2100MHz Cellular amplifier GSM LTE signal repeater kit

Specification:

Frequency			Uplink		Downlink
GSM 900MHz			890-915MHz		935-960MHz
4G 1800MHz			1710-1785MHz		1805-1880MHz
3G 2100MHz			1920-1980MHz		2110-2170MHz
Max. Gain			68dB±2dB		65dB±2dB
Max. Output Power			17dB±2dB		20dB±2dB
Bandwidth			Wide Band
Ripple in Band			≤ 8dB
Noise Figure			≤ 6dB
VSWR			≤ 2.0
Spurious Emission	9KHz~1GHz		≤ -36dBm
	1~12.75GHz		≤ -30dBm
Time Delay			≤ 1.5 μs
MTBF			> 50000 hours
Impedance			50 ohm
Power Supply			AC 90-240V,DC 5V/3A
Power LCD			Power indicator
Alarm LCD		Red	Strong input signal
		Green	Normal
Mechanical Specification
RF Connector				SMA-Female
Cooling				Heatsink Convection cooling
Humidity				< 90%
Operating Temperature				-10°C ~ +55°C
Environment Conditions				IP40
Installation Type				Wall Installation
Size				20.416.44.4cm
Gross Weight				0.8Kg

Further detail pls click here for downloading the products specification:

900+1800+2100MHz A033 RF Repeater.pdf

Selling Point

2022 new upgraded Micro power smart single band signal repeater for residential use with WIFI monitoring and control function, it could cover 100- 300sqm (standard kit), and could support max 2 to 3 indoor antennas to cover over 800sqm. Analog repeater and Digital(Customized Selected Band) repeater for choice.

1,Intelligent to guide the installation with LCD
2,Real time display the signal strength.
3,Automatic dormancy when no user make the calling
4,Automatic alarm when installation mistake and provide the according solution
5,Automatic adjust the system gain to avoid the repeater self-excitation
6,initiative reminding when the device was damaged.

Product Description

We are manufacturer, and have our own factory.

FAQ

Q1. Could I get a sample before bulk order?

Yes, we offer the sample for all models but charged.

Q2. What should I do if I don't know about frequency in my country?

This model is suitable for Asia, Europe, The Middle East, and Brazil, etc.

*For more details please contact us directly.

Q3. Do you accept OEM/ODM order?
Yes, we can customize the brand logo, colors, and frequencies.

Q4.Payment Method
T/T, Western Union, Paypal, and Credit Card are available,
but we suggest paying by Trade Assurance, the most favor, and security method.
*Other methods please contact us with more details.

Q5.Shipment Date

Sample	1-3 business days
<50 pcs	7-15 days
50-100 pcs	15-24 days
>100 pcs	Negotiate

Q6: Delivery Date of the sample by DHL/FedEx

Russia/Canada/Europe/Asia	3-5 days
Middle East/Latin American	3-6 days
African	5-7 days
